Easysplicer OTDRsm

EasySplicer OTDRsm - Optical Time Domain Reflectometer - SingleMode

Professional Tool for Fiber Network Testing and Fault Location

The EasySplicer OTDRsm is a powerful yet easy-to-use instrument designed for fiber network installers. Whether you're a beginner or a seasoned technician, this tool helps you quickly measure fiber length, pinpoint faults, and assess signal loss with precision.

Key Features:

• OTDR (Optical Time Domain Reflectometer) for detecting faults and measuring fiber loss

• Measurement range: 0 to 60 km, with 1-meter resolution

• Loss accuracy: 0.01 dB resolution

• Dual Operation Modes:

  • Auto Mode for quick, beginner-friendly testing

  • Expert Mode for advanced configuration and diagnostics

• 4.3” Multicolor Touchscreen – clear, intuitive display with responsive controls

• Compact, Rugged Carry Case – includes 500m launch cable and 4x adapter cables

• Integrated Functions:

  • OLS (Optical Light Source) – dual wavelengths: 1310nm and 1550nm

  • OPM (Optical Power Meter) – supports 800nm to 1700nm range

  • VFL (Visual Fault Locator) – visually identify fiber faults

  • RJ45 Cable Tracker – measure and trace Ethernet cables (up to 300m)

Designed for Simplicity and Precision

The EasySplicer OTDR is tailored for the everyday fiber installer. With a single tap, the Auto Mode begins a signal sweep to analyze the fiber line—measuring length, dB loss, and detecting any issues such as breaks, bends, or splices. Results are displayed on the bright touch display and can be saved internally or to a microSD card for documentation.

For more advanced needs, Expert Mode allows full control over testing parameters.

All-in-One Testing Solution

Beyond OTDR capabilities, the EasySplicer OTDR includes integrated tools for a complete testing experience:

• Optical Light Source (OLS) for transmitting test signals at 1310nm and 1550nm

• Optical Power Meter (OPM) for measuring signal loss in a wide wavelength range

• Visual Fault Locator (VFL) for fast visual fault detection

• RJ45 Cable Tracker to trace and verify Ethernet cabling, check continuity, and measure length

Everything fits into a compact, durable carry case. The device can even be operated directly from the case to protect it from moisture or debris during fieldwork.

Affordable, Versatile, and Essential

The EasySplicer OTDRsm offers professional-grade functionality at a highly competitive price—making it an essential tool for any fiber installation or maintenance project.
